GRUNDFOS CR 15-2 A-GJ_A-E-HQQE VERTICAL MULTISTAGE CENTRIFUGAL PUMP

GRUNDFOS CR 15-2 A-GJ_A-E-HQQE VERTICAL MULTISTAGE CENTRIFUGAL PUMP

Regular price $6,338.00 USD
Regular price Sale price $6,338.00 USD
Sale Sold out
Shipping calculated at checkout.

This vertical multistage centrifugal pump has suction and discharge ports aligned at the same level. The pump head and base are made of cast iron, while all other wetted components are constructed from stainless steel (EN 1.4301).

    • Grundfos Pump model 99917478, CR15-2 A-GJ-A-E-HQQE, is a vertical multistage centrifugal pump equipped with a WEG motor, designed as a replacement for model CR 15-2 (96523613). It has a power rating of 5 HP and operates at 230/460 volts, 60 Hz, with three-phase (3 Ph) power. This pump features a totally enclosed fan-cooled (TEFC) enclosure, 2 stages, and includes 2" suction and discharge ports with ANSI/JIS flange connections. It is also fitted with a balanced cartridge shaft seal with an O-ring made of silicon carbide and EPDM.

    Brochure

    Data Sheet

    BRAND Grundfos
    PRODUCT TYPE Pump
    MAX FLOW 90.3 gpm
    MAX TEMPERATURE 248 °F
    MAX PRESSURE 362.59 psi
    MAX HEAD 103.7
