GRUNDFOS CR 10-17 K-GJ-A-E-HQQE VERTICAL MULTISTAGE CENTRIFUGAL PUMP

This vertical multistage centrifugal pump has suction and discharge ports aligned at the same level. The pump head and base are made of cast iron, while all other wetted components are constructed from stainless steel (EN 1.4301).

• • Grundfos Pump model 99968300, CR10-17 K-GJ-A-E-HQQE, is a vertical multistage centrifugal pump paired with a WEG motor. It features a power rating of 15 HP and operates at 230/460 volts, 60 Hz, using three-phase (3 Ph) power. The pump includes a totally enclosed fan-cooled (TEFC) enclosure, 17 stages, and has 2" suction and discharge ports with ANSI/JIS flange connections. It is also fitted with a balanced cartridge shaft seal that incorporates an O-ring made of silicon carbide and EPDM.

  .

  Brochure

  Data Sheet

  BRAND	Grundfos
  PRODUCT TYPE	Pump
  MAX FLOW	53.3 gpm
  MAX TEMPERATURE	248 °F
  MAX PRESSURE	362.59 psi
  MAX HEAD	669.9
