FIRE PUMP MOTORS- Ask For Pricing
FIRE PUMP MOTORS- Ask For Pricing
Couldn't load pickup availability
Baldor Fire PUMP MOTORS- Ask For Pricing
Offering a solution for both wet and dry pit applications, the Baldor-Reliance® Submersible motors provide a proven solution for municipal and industrial wastewater operations as well as slurry pumps, aerators and mixers.
WET pit motors use the effluent for cooling and can run 15 minutes in air. DRY pit motors are sized to run continuously in air or submerged even at a depth of 200ft.
The Baldor-Reliance® Immersible motors are designed for use where the possibility of flooding exists. This motor features totally enclosed, blower-cooled enclosures and are designed with a unique sealing system. The system allows reliable operation for a period of two weeks while submerged under a maximum depth of thirty feet of water.
Features
- UL File E481231
- 50/60 Hertz
- 200/400V, 230/460V, 460V
- Rolled Steel and Cast Iron Frames
- Exterior Red Paint RAL3002
- Class F Insulation system
- 1.15 Service Factor, 40° C ambient continuous
- Dual voltage motors 20 Hp and larger have 12 leads, suitable for wye-delta or across the line start on either voltage or part winding start on low voltage
- Single voltage motors have 12 leads and are suitable for wye-delta, across the line or part winding start
- Fire Pump motors are not recommended for use with variable frequency drives.
Common industries
- Fire Suppression
Common applications
- UL listed Fire Pump motors installed per NFPA-20
